150/250V XLPE Insulated, LSOH (SHF1) Sheathed, Armoured Flame Retardant Instrumentation & Control Cables (Multipair/Multitriple)
Feature:
DESCRIPTION
APPLICATION
150/250V IEC60092 STANDARD Offshore & Marine armoured cables are used on board of ships in all locations for fixed installations complying with IEC standards 60092-352. These cables are flame retardant, low smoke& halogen free, suitable for installations on passenger ships, as on other commercial vessels.
Approvals
IEC 60092-350/351/376/359, IEC 60332-1, IEC 60332-3-22, IEC 60754-1/2, IEC 61034
Technical data
a.Temperature range:
during installation:
fixed installed: -30 °C up to+90 °C
at short circuit of max. 5 s: 250
b.Nominal voltage: 150/250V
d.Minimal inner bending radius: 6×OD
during installation:
fixed installed: -30 °C up to+90 °C
at short circuit of max. 5 s: 250
b.Nominal voltage: 150/250V
d.Minimal inner bending radius: 6×OD
SPECIFICATIONS
Low Voltage
Working Temperature 90℃
Flame Retardant
CONSTRUCTION
- Conductor:Class 2 stranded copper conductor.
- Insulation:XLPE.
- Cabling Element:Pair/Triple.
- Inner Covering:Lapped polyester tape.
- Armour:Copper wire braid.
- Outer Sheath:LSOH (SHF1). SHF2 can be offered upon request.
- possible insulation colors:Pair: White/blue with printed pair number and core number.
Triple: White/blue/red with printed triple number.
PARAMETER
- 2×0.75 (CORES×CROSSSECTION)
- 2×1.0 (CORES×CROSSSECTION)
- 2×1.5 (CORES×CROSSSECTION)
- 3×0.75 (CORES×CROSSSECTION)
- 3×1.0 (CORES×CROSSSECTION)
- 3×1.5 (CORES×CROSSSECTION)
| CONSTRUCTION | NOMINAL INSULATION THICKNESS | NOMINAL SHEATH THICKNESS | NOMINAL OVERALL DIAMETER | NOMINAL WEIGHT |
| NO. OF ELEMENTS×NO. OF CORES IN ELEMENT×CROSSSECTION | ||||
| (MM²) | MM | MM | MM | KG/KM |
| 1×2×0.75 | 0.5 | 1.2 | 8.1 | 90 |
| 2×2×0.75 | 0.5 | 1.3 | 9.3 | 130 |
| 3×2×0.75 | 0.5 | 1.4 | 12.4 | 200 |
| 4×2×0.75 | 0.5 | 1.4 | 13.1 | 230 |
| 5×2×0.75 | 0.5 | 1.8 | 15.2 | 320 |
| 6×2×0.75 | 0.5 | 1.8 | 16.1 | 350 |
| 7×2×0.75 | 0.5 | 1.8 | 16.1 | 370 |
| 8×2×0.75 | 0.5 | 1.9 | 17.2 | 420 |
| 10×2×0.75 | 0.5 | 1.9 | 19.1 | 500 |
| 12×2×0.75 | 0.5 | 2 | 20 | 560 |
| 14×2×0.75 | 0.5 | 2 | 20.6 | 610 |
| 16×2×0.75 | 0.5 | 2.1 | 22.2 | 690 |
| 19×2×0.75 | 0.5 | 2.1 | 23.6 | 790 |
| 20×2×0.75 | 0.5 | 2.1 | 23.6 | 800 |
| 24×2×0.75 | 0.5 | 2.2 | 26.8 | 980 |
| 30×2×0.75 | 0.5 | 2.3 | 29.1 | 1160 |
| 37×2×0.75 | 0.5 | 2.4 | 31.1 | 1360 |
