0.6/1 kV XLPE Insulated, LSOH (SHF1) Sheathed Flame Retardant Power & Control Cables.
0.6/1 kV IEC60092 STANDARD Offshore & Marine unarmoured power & control cables are used on board of ships in all locations for fixed installations not subject to mechanical risk complying with IEC standards 60092-352. These cables are flame retardant, low smoke & halogen free.
DESCRIPTION
APPLICATION
Approvals
IEC 60092-350/351/353/359, IEC 60332-1, IEC 60332-3-22, IEC 60754-1/2, IEC 61034
Technical data
a.Temperature range:
during installation:
fixed installed: -30 °C up to+90 °C
at short circuit of max. 5s: 250
b.Nominal voltage: 0.6/1 kV
c.Test voltage: 3500V
d.Minimal inner bending radius: 6×OD (OD>25mm); 4×OD (OD ≤25mm)
during installation:
fixed installed: -30 °C up to+90 °C
at short circuit of max. 5s: 250
b.Nominal voltage: 0.6/1 kV
c.Test voltage: 3500V
d.Minimal inner bending radius: 6×OD (OD>25mm); 4×OD (OD ≤25mm)
SPECIFICATIONS
Low Voltage
Flame Retardant
CONSTRUCTION
- Conductor:Class 2 stranded copper conductor, round or sector shaped. Class 5 stranded conductors can be offered upon request.
- Insulation:XLPE. HEPR insulation can be offered upon request.
- Outer Sheath:LSOH (SHF1). SHF2 can be offered upon request.
- possible insulation colors:Single core: Black
Two cores: Blue, Brown.
Three cores: Brown, Black, Grey.
Four cores: Blue, Brown, Black, Grey.
Five cores: Blue, Brown, Black, Grey, Black.
Multi cores: White with black numbers.
With yellow/green (optional)
Two cores + earth (3G): Yellow/green, Blue, Brown.
Three cores + earth (4G): Yellow/green, Brown, Black, Grey.
Four cores + earth (5G): Yellow/green, Blue, Brown, Black, Grey.
PARAMETER
- Single Core
- Multi Cores
| CONSTRUCTION | NOMINAL INSULATION | NOMINAL SHEATH THICKNESS MM | NOMINAL OVERALL | NOMINAL WEIGHT KG/KM |
| NO. OF CORES×CROSS | THICKNESS MM | DIAMETER MM | ||
| SECTION(MM²) | ||||
| 1×1.5 | 0.7 | 1 | 5 | 40 |
| 1×2.5 | 0.7 | 1 | 5.4 | 50 |
| 1×4 | 0.9 | 1.04 | 6.4 | 70 |
| 1×6 | 0.9 | 1.04 | 7 | 90 |
| 1×10 | 0.9 | 1.04 | 7.9 | 130 |
| 1×16 | 0.9 | 1.04 | 8.9 | 190 |
| 1×25 | 0.9 | 1.1 | 10.4 | 295 |
| 1×35 | 0.9 | 1.1 | 11.7 | 380 |
| 1×50 | 1 | 1.2 | 13.3 | 510 |
| 1×70 | 1.1 | 1.3 | 15.5 | 720 |
| 1×95 | 1.1 | 1.3 | 17.4 | 970 |
| 1×120 | 1.2 | 1.4 | 19.4 | 1220 |
| 1×150 | 1.4 | 1.5 | 21.5 | 1505 |
| 1×185 | 1.6 | 1.5 | 23.8 | 1865 |
| 1×240 | 1.7 | 1.6 | 26.7 | 2420 |
| 1×300 | 1.8 | 1.7 | 29.6 | 3015 |
