DESCRIPTION
APPLICATION
LiYCY cable can be used for signal transmission between electronic devices, in computer systems or process control units with increased electromagnetic compatibility requirements.
Standards:
VDE 0482-332-1-2, EN 60811-2-
Flame Retardant according to: IEC 60332-1
Flame Retardant according to: IEC 60332-1
Characteristics
Voltage Rating Uo/U: 250/250V
Voltage Test: 1.2kV
Temperature Rating Fixed: -30ºC to +180ºC Installation: -5ºC to +70ºC
Minimum Bending Radius
Fixed Installation: 6 x overall diameter
Voltage Test: 1.2kV
Temperature Rating Fixed: -30ºC to +180ºC Installation: -5ºC to +70ºC
Minimum Bending Radius
Fixed Installation: 6 x overall diameter
SPECIFICATIONS
Low Voltage
Flame Retardant
CONSTRUCTION
- Conductor:Class 5 Fine Stranded Bare Copper
- Insulation:PVC (Polyvinyl chloride)
- Screen:TCWB (Tinned Copper Wire Braid)
- Outer Sheath:PVC (Polyvinyl chloride)
PARAMETER
- 0.75 mm2 Conductor Size
- 1 mm2 Conductor Size
- 1.5 mm2 Conductor Size
Conductor Size | Approximate net weight of Cu | Approximate net weight of cables | Maximum conductor resistance at temperature 20°C | ||
| (mm2) | (kg/km) | (kg/km) | |||
| 2 | * | 0.75 | 25.98 | 38.5 | 26 |
| 3 | * | 0.75 | 32.85 | 45.6 | 26 |
| 4 | * | 0.75 | 41.37 | 55.6 | 26 |
| 5 | * | 0.75 | 49.35 | 65.1 | 26 |
| 7 | * | 0.75 | 64.96 | 82.7 | 26 |
| 8 | * | 0.75 | 74.16 | 94.2 | 26 |
| 10 | * | 0.75 | 91.35 | 114.6 | 26 |
| 12 | * | 0.75 | 106.17 | 130.4 | 26 |
| 18 | * | 0.75 | 153.48 | 182.8 | 26 |
| 25 | * | 0.75 | 207.72 | 243.5 | 26 |
| 30 | * | 0.75 | 244.37 | 282.6 | 26 |
