RAYCHEM D-436-37 High Performance Immersion-Resistant Butt Splice, 1.69 mm ID Barrel, 20 to 16 AWG Part # D436-37=7S
Feature:
DESCRIPTION
MORE INFORMATION
NSN
5940-00-271-7741
Country Of Origin
Mexico
ECCN / USML
EAR99
Schedule B
8536904000
Dimensions (L x W x H)
1.13 x .19 x .19 IN
Total Shelf Life (days)
No Information
Hazmat Code
-
Package Weight
.01 LB
FAA Approval Code
STD
Hazmat(Y/N)
N
LTL(Y/N)
N
8130-3 Eligible
No
TECHNICAL INFORMATION
• EU Directive 2011/65/EU
• EU ELV Directive 2000/53/EC
• EU Reach Regulation (EC) No. 1907/2006
• RoHS Compliant
SPECIFICATIONS
• Series: MiniSeal
• Length: 29.21 mm
• Barrel Size: 1.69 mm ID
• Barrel Type: Closed
• Insulated/Non-Insulated: Insulated
• Insulation Material: Polyvinylidene
• Dielectric Strength: 2.5 kV
• Wire Size: 20 to 16 AWG
• Color: Blue
• Finish: Tin-Plated
• Temperature Rating: -55 to 150 deg C
• Domestic/Import: Import
APPLICATIONS
• For hundreds of aerospace and defense applications
