China Famous Brand SANY Concrete Machinery TRAILER PUMP HBT4008C-5I
Feature:
Theo.delivery pressure: 8Mpa
Theo.concrete output: 41m³/h
Engine rated power: 49KW/2100rpm
DESCRIPTION
Sany HBT4008C-5I trailer pump has maximum output of 41 cubic meter per hour, equipped with self-diagnosis technology monitoring the pump status at any time as well as diagnosing more than 50 faults in real time. The 41 cubic meter trailer pump is capable of reducing the troubles shooting time by 70%, granting you both time and peace of mind.
5 Key Pump Technology
ADVANCED HYDRAULIC SYSTEM
Differential pressure controlled, bi-directional hydraulic system.
Sany trailer mounted concrete pump hydraulic system pump controls use differential pressure sensing technology and bi-directional pumps. The bi-directional pumps feature smooth direction change abilities. The open loop charge system continually circulates the hydraulic oil for filtration and cooling. The constant supply of filtered, cooled hydraulic oil prolongs equipment life and lowers maintenance costs.
High flow, high efficiency valve system
Our system adopts a high pressure, high flow electro-hydraulic main control valve and an integrated valve with optimized tubing design and layout. The system features a short reversing design, low pressure loss, low temperature and high reliability.
Automatically retracted pistons
With the press of a button, the two pistons return to the water tank. This reduces daily maintenance time and extends the life of the pistons.
INTELLIGENT CONTROL SYSTEM
Fault self-diagnosis technology
The intelligent control system monitors the machine for over 50 faults in real time. Faults are displayed on the monitor. Review of the faults can reduce troubleshooting time by 70%.
Dedicated motion controller
Entirely different from conventional motion controllers,the Sany controller integrates the pumping algorithm with an onboard database. The result is faster operation and superior performance.
Emergency Override Available
In case of a fault during operation, an emergency override mode is available for cleanout and shutdown.
EFFICIENT PUMPING SYSTEM
High-efficiency pump technology
The hydraulic system pump controls use differential pressure sensing technology and bi-directional pumps. The bi-directional pumps feature smooth direction change abilities. This allows efficient pumping action and precise swing cylinder control.
High power mixing motor
High displacement mixing motor keeps the mixture properly conditioned.
Large bore reversing cylinder
The large bore reversing cylinder allows powerful reversing to prevent pipe blockage.
New-type hopper
The hopper's inner cavity has been optimized to improve aggregate mixing and to high density, complex concrete.
ADVANCED ENERGY-SAVING TECHNOLOGY
New generation energy saving technology automatically adjusts engine power output to match the load results in fuel savings of up to 25%.
WEAR-RESISTING TECHNOLOGY
G5 improved wearing part Adopt Sino-Germany high-tech materials and advanced technology to greatly improve the product performance.
