1、IMC、IMCX 型塑料磁力离心泵(可带夹套)IMC Plastic Magnetic Drive Centrifugal Pump(with jacket)

1. 泵体；2.叶轮螺母；3.叶轮；4.密封垫；5.止推轴承；6.滑动轴承；7.轴套；8.中体；9泵轴；10.密封圈；11.隔离套；12.外磁钢；13.内联磁钢；14.螺母；15、16 轴承；17.轴；18.加长联轴器；19.后轴承压盖；20.托架；21.前轴承压盖；22.悬架1.casing； 2.impeller nut; 3.impeller ; 4.gasket; 5.thrust bearing; 6.journal bearing; 7.shaft sleave;8.ioint; 9.pump shaft; 10.gasket ring; 11.shroud; 12.out magnetic; 13.innermagnetic; 14.nut; 15.16.bearing; 17.shaft; 18.extended coupling; 19.oil seal cover; 20.liftstand; 21.oil seal cover; 22.suspension

2、IMC 型金属磁力离心泵(带夹套、带自吸)IMC Metal Magnetic Centrifugal Pump(with Jacket, self-suction)

1.泵体；2.叶轮螺母；3.密封环；4.叶轮；5.密封垫；6.止推轴承；7.滑动轴承；8.轴套；9.中体；10.泵轴；11.密封圈；12.隔离套；13.外联轴器；14.内联轴器；15.螺母；16、17轴承；18.轴承压盖；19.轴；20.加长联轴器；21.托架；22.悬架

1.casing; 2.impeller nut; 3.seal ring; 4.impeller; 5.gasket; 6.thrust bearing; 7.journal bearing; 8.shaft sleave; 9 .joint; 10.pump shaft; 11.gasket ring; 12.shroud; 13.out magnetic coupling 19.shaft; 20.extendedcoupling; 21.lift stand; 22.suspension 19.shaft; 20.extended coupling; 21.lift stand; 22.suspension

3、IMC 型金属磁力离心泵(带夹套)；IMC Metal Magnetic Drive Centrifugal Pump(with Jacket)

1.泵体；2.叶轮螺母；3.密封环；4.叶轮；5.密封垫；6.止推轴承；7.滑动轴承；8.轴套；9.中体；10.泵轴；11.密封圈；12.隔离套；13.外联轴器；14.内联轴器；15.螺母；16、17轴承；18.轴承乐善19.轴；20.加长联轴器；21.托架；22.悬架

1 .casing; 2.impeller nut; 3.seal ring; 4.impeller; 5.gasket; 6.thrust bearing; 7.journal bearing; 8.shaft sleave; 9 .joint; 10.pump shaft; 11 .gasket ring; 12.shroud; 13.out magnetic coupling; 19.shaft; 20.extendedcoupling; 21.lift stand; 22.suspension 19.shaft; 20.extended coupling; 21 .lift stand; 22.suspension

4、IMC 型自吸式金属磁力离心泵; IMC Metal Magnetic Drive Centrifugal Pump (self-suction)

1.泵体；2.叶轮螺母；3.密封环；4.叶轮；5.密封垫；6.止推轴承；7.滑动轴承；8.轴套；9.中体；10.泵轴；11.密封圈；12.隔离套；13、外联轴器；14,内联轴器；15.螺盘；16、17轴承；18轴承压善；19轴；20.加长联轴器；21.托架；22.悬架

1.casing; 2.impeller nut; 3.seal ring; 4.impeller; 5.gasket; 6.thrust bearing;7.journal bearing; 8.shaft sleave; 9.joint;; 10.pump shaft; 11.gasket ring; 12.shroud; 13.out magnetic coupling 14.inner magneticcoupling; 15.nut; 16.17.bearing; 18.oil seal cover 19.shaft; 20.extended coupling; 21 .lift stand; 22.suspension
