DESCRIPTION
APPLICATION
Primary power and distribution circuits in industrial and commercial installations, power circuits in generating plants where line to ground fault current are within shield capabilities. May be used in wet or dry locations, installed in underground, duct, or direct burial.
Standards:
UL 1072 Medium Voltage Power Cables.
ICEA S-94-649 5 kV – 46 kV Shielded Power Cables.
AEIC CS8 Standard for Utility Shielded Power Cables Rated 5 kV – 46 kV.
ICEA S-94-649 5 kV – 46 kV Shielded Power Cables.
AEIC CS8 Standard for Utility Shielded Power Cables Rated 5 kV – 46 kV.
Specifications
Maximum operating voltage:
• 5 kV to 46 kV 100% and 133% IL Maximum conductor operation temperatures:
Wet and dry locations
• Normal: 90 °C
• Emergency: 140 °C
• Short Circuit: 250 °C
• 5 kV to 46 kV 100% and 133% IL Maximum conductor operation temperatures:
Wet and dry locations
• Normal: 90 °C
• Emergency: 140 °C
• Short Circuit: 250 °C
Optional
1. Sealed conductor with strand filled compound passes the production water penetration tests per ICEA-T-31-610 at 15 psi for 60 minutes.
2. Dual sealed cable (Strand Filled on conductor and Neutral wires) meets the water penetration requirements in accordance with ICEA-T-34-664.
2. Dual sealed cable (Strand Filled on conductor and Neutral wires) meets the water penetration requirements in accordance with ICEA-T-34-664.
SPECIFICATIONS
UV Resistance
Medium Voltage
Water Resistance
Working Temperature 90℃
CONSTRUCTION
- Conductor:Soft annealed uncoated copper compressed Class B per ASTM B496 or hard drawn Aluminum-1350 compressed Class B per ASTM B231.
- Conductor Shield:Semi conducting cross-linked polyethylene compound (XLPE compound).
- Insulation:Thermoset ethylene propylene rubber(EPR).
- Insulation Shield:Semi conducting cross-linked polyethylene compound (XLPE compound).
- Metallic Shield:Solid soft annealed copper wires per ASTM B3, helically applied and uniformly spaced. Or copper tape shield.
- Jacket:Extruded to fill, Black sunlight resistant linear low density polyethylene (LLDPE), with three Red Stripes. Or PVC.
PARAMETER
- 5kV EPR insulation
- 8kV EPR insulation
- 15kV EPR insulation
- 15kV EPR insulation
- 25kV EPR insulation
- 25kV EPR insulation
- 35kV EPR insulation
- 35kV EPR insulation
| 1/3 Neutral | Full Neutral | |||||||||||||||
| Size AWG or | Number of Strands | Nominal OD Over Insulation | Number of Wires | Size | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight | Size AWG or | Number of Strands | Nominal OD Over Insulation | Number of Wires | Size | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight | |
| kcmil | - | in | - | AWG | mil | in | lb/kft | kcmil | - | in | - | AWG | mil | in | lb/kft | |
| Copper 100% Insulation Level (90 mil) | ||||||||||||||||
| 2 | 7 | 0.5 | 6 | 14 | 50 | 0.81 | 484 | 2 | 7 | 0.5 | 16 | 14 | 50 | 0.81 | 604 | |
| 1 | 19 | 0.54 | 7 | 14 | 50 | 0.84 | 564 | 1 | 19 | 0.54 | 13 | 12 | 50 | 0.88 | 747 | |
| 1/0 | 19 | 0.58 | 9 | 14 | 50 | 0.88 | 672 | 1/0 | 19 | 0.58 | 16 | 12 | 50 | 0.92 | 889 | |
| 2/0 | 19 | 0.63 | 11 | 14 | 50 | 0.93 | 799 | 2/0 | 19 | 0.63 | 13 | 10 | 50 | 1 | 1109 | |
| 3/0 | 19 | 0.68 | 14 | 14 | 50 | 0.98 | 963 | 3/0 | 19 | 0.68 | 16 | 10 | 50 | 1.05 | 1331 | |
| 4/0 | 19 | 0.73 | 18 | 14 | 50 | 1.03 | 1170 | 4/0 | 19 | 0.73 | 16 | 9 | 50 | 1.14 | 1637 | |
| 250 | 37 | 0.79 | 13 | 12 | 50 | 1.12 | 1366 | 250 | 37 | 0.79 | 25 | 10 | 50 | 1.17 | 1910 | |
| 350 | 37 | 0.89 | 18 | 12 | 50 | 1.23 | 1815 | 350 | 37 | 0.89 | 22 | 8 | 50 | 1.32 | 2614 | |
| 500 | 37 | 1.02 | 17 | 10 | 50 | 1.42 | 2569 | 500 | 37 | 1.02 | 31 | 8 | 50 | 1.47 | 3603 | |
| 750 | 61 | 1.21 | 20 | 9 | 80 | 1.7 | 3773 | — | — | — | — | — | — | — | — | |
| 1000 | 61 | 1.36 | 26 | 9 | 80 | 1.85 | 4854 | — | — | — | — | — | — | |||
