China Strong Power Low Cost Rock Core Drill XDY1500


rated power: 152kW

rated RPM: 2200r/min

max torque: 5200Nm


1. The CUMMINS high-power engine is powerful and forceful which can satisfy the construction requirement in bad conditions;

2. These drills are adopted the advanced control technique includes load sensitive control electro-hydraulic proportion control, and the usage of the import hydraulic parts can make the system work stably and ensure the quality;

3. The machine adopts single row rope for main winch to figure out the wear of steal rope, and extend the lifespan;

4. With the cylinder used for the pull-down of the rotary drive, the system works smoothly and steadily;

5. Electromechanical-hydraulic jointly control method is adapted for the rotary drive, stepless speed regulation. Reasonable torsion-speed rate can meet the construction of varying layer;

6. Home-made undercarriage steel apron wheel,the moving of the machine is controlled by the line which is convenient and safe;

7.Adapting safe operation control system can avoid misoperation and make the manipulation more convenient and security;

8.Adapting independent energy conservation and environment protection oil cooler can make the hydraulic system more adaptive in complicated surroundings.
